Weighing Assemblies - 50,000kg (50t) to 200,000kg (200t) capacity

Thames Side's range of weighing assemblies offers design engineers, scale manufacturers and site engineers the most advanced weighing assembly technology. Thanks to our industrial experience spanning more than 40 years, you can be sure that if you specify Thames Side weighing assemblies then you are selecting benchmark solutions that provide the best quality/price ratio. We offer the following models of weighing assembly from 50,000kg (50 tonnes) to 200,000kg (200 tonnes) capacity per assembly.

If you are searching for the best available silo, hopper and tank weighing assemblies, the VC3500 is the industry benchmark high capacity weighing assembly with ease of installation and mechanical integrity at the heart of its design. Thanks to its high accuracy, fully welded, hermetically sealed load cell and its durable, strong mounting accessory it combines excellent weighing performance with low cost of ownership

The Model T30 weighing assembly, with its compression load cell and integrated mounting accessory, is a popular solution for very large silos, thanks to its ease of installation; it can be installed in one step due to its integral design. The detachable cable connector simplifies the electrical installation in the case of eventual replacement. It can easily accommodate steelwork misalignment and the large thermal expansions/contractions of large silos or tanks, without the weighing performance being affected.

For weighing of silos, hoppers or tanks in remote areas where lightning damage is a concern, the T34 Silo Mount weighing assembly combines the popular T34 rocker column load cell with in-built lightning surge arrestors and a zinc plated assembly; this provides a rugged weighing system that is protected from the elements.

CE-mark-transparent  All of our weighing assemblies manufactured since July 2014 are RoHS 2 compliant.

To create a complete weighing system, Thames Side also offers an extensive range of junction box options and high precision measuring electronics; this ensures that optimum performance is achieved in all weighing applications.

Contact Us or Find our Local Partner nearest you for more information and a fast quotation.

VC3500 weighing assembly

VC3500 (50,000kg - 200,000kg)

  • Benchmark solution in silo/tank/vessel weighing
  • Stainless steel load cell
  • Zinc plated steel mounting accessory (options of galvanised steel, special paint or stainless steel)
  • 30,000kg to 200,000kg capacity range
  • IP68 and IP69K, ATEX, IECEx
  • EN1090 approval with CE marking available as an option
Weighing Assemblies - above 200,000kg (200t) capacity

T30 Weighing Assembly (100,000kg - 200,000kg)

  • Simple installation for high capacity silos and tanks
  • Compression column load cell; painted steel mounting accessory
  • 100,000kg to 600,000kg capacity range
  • IP67

T34 Silo Mount Assembly (60,000kg - 200,000kg)

  • Stainless steel compression rocker column load cell
  • 10,000kg to 1,000,000kg capacity range
  • OIML approval (at some capacities)
  • IP68/IP69K
  • ATEX

Are you are looking for a replacement of an older model of weighing assembly?  Or can you not find what you are looking for?  Please Contact Us.
