Single Point (Platform) Load Cells

Thames Side’s range of single point (platform) load cells has amongst the highest specifications in the market for process weighing applications. They are designed specifically for high accuracy applications in filling and dosing systems, platform scales, multihead weighers, check-weighers and bagging machinery, amongst others. Each model is designed and individually calibrated to be insensitive to off-centre loads.

T2 with logo

T2 (5kg - 50kg)

  • Aluminium alloy
  • 3000 divisions performance
  • Protected to IP66
T4 with logo

T4 (0.3kg - 3kg)

  • Aluminium alloy
  • 3000 divisions performance
  • Protected to IP66
T5 with logo

T5 (3kg - 100kg)

  • Aluminium alloy
  • 3000 divisions performance
  • Protected to IP66
T6 with logo

T6 (5kg - 35kg)

  • Aluminium alloy
  • 4000 divisions performance
  • Protected to IP66
  • Integrated overload stop
T11 with logo

T11 (15kg - 150kg)

  • Nickel plated alloy steel
  • OIML C3 approval up to 75kg capacity
  • Protected to IP66
  • Durable polyurethane cable
T12A with logo

T12A (50kg - 400kg)

  • Nickel plated alloy steel
  • OIML C4 approval
  • Protected to IP66
  • Durable polyurethane cable
  • 2 body sizes
T12 with logo

T12 (15kg - 400kg)

  • Stainless steel
  • OIML C3 approval
  • Fully welded and hermetically sealed
  • Protected to both IP68 and IP69K
  • Optional ATEX approval
  • Durable 6-wire polyurethane cable
  • 2 body sizes
T16 with logo

T16 Fluid Damped (5kg - 35kg)

  • High accuracy and fast settling time with off-centre dynamic loads - ideal for checkweighing
  • Bi-directional overload protection
  • OIML C4 approval
  • 316 stainless steel housing
  • Protected to IP68
  • Durable 6-wire polyurethane cable



The models T2T4T5 and T6 are manufactured from high quality aluminium alloy, with humidity-resistant silicone potting. They are a cost effective single point load cell solution.

For use in harsh environments, our Model T12 stainless steel single point is fully welded and hermetically sealed to provide total environmental protection. The new T12D digital load cell also provides the best possible protection for applications that demand high speed and high precision at the same time - which is challenging.

For less severe environments, our model T11 and T12A nickel plated steel load cells are constructed with humidity-resistant silicone potting.

For dynamic applications such as high speed checkweighing, our fluid damped T16 model has OIML approval, a grade 316 stainless steel housing, integrated bi-directional stop for protection against overloads and a Polyurethane cable for excellent resistance to chemicals.

For very high speed, high precision applications the new T12D digital load cell is available.  It is ideal if you are developing a new high speed checkweigher, high speed sorting machine, high speed packaging machine or high speed filling machine and you require the fastest possible processing speed as well as the highest levels of precision and repeatability. The T12D also connects directly to a PLC and delivers its output in weight units (not in mV/V like analogue / analog load cells) so there is no need for a separate signal amplifier or weight transmitter.  It is a very cost-effective digital load cell with 1,000,000 signal counts and a data capture rate of 1600 measurements per second.

Ex Approvals: the T12 has optional ATEX and IECEx approval for use in hazardous areas.  For use in ATEX dust zones 20, 21 and 22 there is no need for safety barriers.

Most of our single point (platform) load cells carry certified "weights and measures" approval according to OIML R60 C3 or C4.  We can supply technical drawings and 3D CAD files (e.g. in STEP format) to engineers who are specifying load cells for new equipment.

logos 3  All of our load cells manufactured since July 2014 are RoHS 2 compliant.

Complementing our single point load cells is a wide range of precision measuring electronics to provide an optimum weighing solution in a diverse range of applications.

We hold an extensive stock of standard products at our warehouse in the United Kingdom and our Global Network of carefully selected Partners also carries stock, so that products can be shipped immediately on request.

Contact Us or Find our Local Partner nearest you for more information and a fast quotation.



Further information

Contact Thames Side now to discuss your requirements for single point (platform) load cells in any application. We have the experience and applications knowledge to provide expert guidance on the optimum solution for you.
